    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40

    Ask Lasest Price
    Model Number : KK-HV
    Brand Name : kingkongbattery
    Certification : CE/UN38.3/MSDS
    Price : $2,998.00 - $6,408.00/pieces
    • Product Details
    • Company Profile

    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40

    Battery Specifications
    Nominal Capacity
    15.36KWH
    20.48KWh
    25.6KWh
    30.72KWh
    35.84KWh
    40.96KWh
    Cell Matching
    48S1P
    64S1P
    80S1P
    96S1P
    112S1P
    128S1P
    Working Voltage Range
    124.8-172.8V
    166.4-230.4V
    208-288V
    249.6-345.6V
    291.2-403.2V
    332.8-460.8V
    Nominal Voltage
    153.6V
    204.8V
    256.0V
    307.2V
    358.4V
    409.6V
    Weight
    175kg/202kg
    223kg/252kg
    271kg/301kg
    319kg/351kg
    367kg/401kg
    415kg/452kg
    Dimension
    (WxDxH)
    530*480 *
    760mm
    530*480*
    920mm
    530*480*
    1080mm
    530*480*
    1240mm
    530*480*
    1400mm
    530*480*
    1560mm
    Battery Type
    LFP(LiFePO4)
    Nominal Working Current
    50A
    Communication Port
    CAN/RS485
    Working Temperature Range
    Charge:0-45C/Discharge:-10-50℃
    Waterproof
    IP55
    Installation Method
    Floor-standing
    Cycle Life
    6000 times
    Peak Charge/Discharge Current
    50A
    Discharge Rate of Module
    ≤3.5%/month/@25℃
    Module Series Connection /Module
    8S~16S
    Parallel Connection
    20 units in parallel
    Support Inverter Brand
    Victron,Pylon,Deye,SMA,Growatt,Goodwe,MPP,Voltronicpower,Pchne,Megarevo.....
    Warranty
    10 years
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    ①:P+ battery output positive pole
    ⑥: External communication port (parallel cluster / debugging communication)
    ②:P- battery output negative pole
    ③: Circuit breaker switch
    ⑦: PCS communication port (communication with PCS)
    ④: Battery box communication port
    ⑧:B+ battery input positive pole
    ⑤: CAN communication port (communication with PCS)
    ⑨:B- battery output negative pole
    Products Description
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    High voltage system
    Better energy utilization than low-voltage system
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    Built In BMS
    Battery modular with Built in high qualityBMS. Protect battery all the way
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    Safety
    With Lithium iron phosphate battery
    Stay safe with battery storage at Home
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    Long Life
    Span15-20 years Life design.
    Up to 6000 + Cycle llfe
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    Stackable
    Battery modular is Stackable for any
    larger Storage System.
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    Installation Easy
    ground stock brick
    Simply connecting to inverter.
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40 Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40 Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40 Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    About KingKongBattery
    KingKong batterynow have enough stock in
    China/Poland EU/US/CA/UK location for the
    (1)3.2V LiFePO4 cell
    (2)12V LiFePO4 battery pack
    (3)48V energy storage system.
    It's best time to have quick shipping!
    Talk Leo(Click here) to get more details
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    Why KingKongBattery is your BEST Partner?

    --Your Expert For Power Solution:

    With 13 years of experience in the battery industry, KingKong battery has served over 12,000 cusTomers from 80+ countries. We have 4 overseas warehouses
    Because of maintaining a repurchase rate of over 90%, an on-time delivery rate of 99.5%, and receiving 98% positive feedback rated by RFQ, we have received RFQ's recommendation.
    --Source Factory & Direct Distributor:
    We are direct distributors for EV, CATL, LISHEN, CALB, and REPT batteries.
    All batteries are 100% original Grade A and brand new.
    We maintain weekly fresh stock with newly produced cells, ensuring long-term supply for your projects without worrying about stock availability.

    --Guaranteed Quality Service:
    We guarantee 100% tested batteries, ensuring strict testing before shipment with matched voltage and IR. We welcome QC checking and online video checking before shipping.
    --Fully Warranty Service Guaranteed:
    KingKong battery has self-operated overseas warehouses and repair centers in Poland and Germany, providing 100% product usage guidance and technical support. For products confirmed to have non-artificial quality issues, we offer complete after-sales service, ensuring worry-free shopping for you.
    --OEM / ODM Supported:
    With an experienced team of energy storage structural and software engineers, we offer flexible customization services. Additionally, our marketing team provides one-on-one support, offering a full range of marketing solutions and services to help you expand your business in local markets.
    Send an inquiry NOW(Click here)
    Leo is here at your service to help you get guaranteed power.
    --------------------------------
    Real customer feedback

    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40



    Just like the partners below
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    How we guarantee TOP quality?
    Grade A CELL 100% Brand New with Original QR code !!!!!
    QR CODE Scanner
    VERIFIED QR CODE
    Talk Leo(Click here) to get more details

    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40

    All Single battery must test over 3 times before shipping,
    to make sure they are in top quality level,
    with full capacity, matched voltage & internal resistance.
    Please contact Talk Leo(Click here) to learn more about our offer. Thanks.
    Reliability TEST
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    Top Equipment & Production
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40 Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    Accessories you will also need
    KingKong battery are Official distributor of EVE/ HC/NDSD brand and Supply other safety Pack accessories together Just show us what kinds of BMS you need.
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
    Leo will quote the RIGHT BMS/KITS and accessores together.
    100% technicial support
    100% after-sales support
    Talk Leo(Click here) to get more details
    Inverter Protocol Matching

    BMS Inverter Communication Protocol Matching Table

    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40

    Packing & Shipping
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40

    FAQ
    DIY battery packmust get the cellsbalanced (same voltage )before assembly. Later if there happens don't know how to assembled or wrong assembly is not accepted refund. Professionals will detectedvoltage/resistance/appearanceand other issues before every shipment, we can only ensure that the single battery is good, when arrival you can test the cells within 15 days, after that means batteries have no problem, does not provide return nor refund. If you found problems you can contact us for return or refund.Battery can only be unused(the electrode intact, no welding, no wear, the appearance good)to provide return. Any return behavior buyers need to be responsible for shipping fee.

    1).Warranty period:5 years(from the date of successful delivery),if the single battery capacity less than 80% initialcapacity,take the test pictures or video to us,we will replace it or give satisfied solution.
    2).If any miss or damaged for the shipping. Please contact us firstly, then send us the picture or video to check. In case oflossof cargo or the battery is damaged and can not be used or there is a greater risk of use,we will communicate with buyer if resend it or replace it or refund the product cost.If buyer send back the cells to seller,buyer should pay for the shipping cost.
    3).These situations not provide return nor refund
    1. After the assembly or assembly process happen any problem, such as theprotection board connected to the wrong wire burned lead to battery damage, charger failure, the assembly error or unbalanced assembly, etc.
    2. For damage caused , such as battery bulge/welded, battery pack without protection BMS caused by charging.
    Tips:
    * These products are prototype batteries without protection board, you need to purchase a match one! Pls click here to consult us.
    * please consider before taking orders, place order means you have agreed. thank you for your cooperation!
    Hybrid Grid Connection Widely Matched Inverter LFP Modular Stacked High Voltage Battery Home Energy Storage System 15-40
